Vturn 40 / 425

Victor Vturn 40 / 425 Horizontal Turning Lathe

  • Heavy cutting lathe with spindle nose A2-11 for turning length from 1250mm to 4250mm.
  • Bar capacity 91mm, Spindle speed 2500rpm.
  • Single piece cast slant bed (45-degree) for minimum distance from ball screw to the tool tip
  • Spindle bore A2-11 with hydraulic chuck 15” (opt. 12”)
  • Genuine 45∘one piece slant bed for maximal structure rigidity
  • Large ballscrew diameter in Z-axis: 50mm Vturn-40/125 & Vturn-40/220, 63mm for Vturn-40/325, 70mm for Vturn-40/425
  • Y-axis & C-axis applications available with built-in spindle for contour milling.


Description

Specifications
MACHINE CAPACITY
Swing over bedmm780
Std. Turning dia.mm520
Max. turning dia.mm620 [560/580] (390 for CV)
Swing over carriagemm620
Center distancemm4285
Hole through draw barmm91 (opt. 105 for CV/(Y)CM)
AXIS FEEDS
X axis travel: – Std turretmm310+30
X axis travel: – VDI turretmm125+315
X axis travel: – VDI turret, C-axismm107+165
X axis travel: – BMT turret, C-axismm280+90 / 290+50
Z axis travelmm4250
Y axis travelmm±80
Rapid feed – X/Z axism/min20/8
Rapid feed – Y axism/min7
Feed motor – X/Z axiskW4 / 6 (@40_38Nm) [7 / 6 (@40i)]
Feed motor – Y axiskW4
JOG feed ratemm/min0~1260
Ball screw dia x pitchmm70 x P12 (Z)
SPINDLE
Spindle nose (chuck)inchA2-11 (15″)
Max. spindle speedrpm2500
Spindle motor powerkW30/37 with gearbox (37/45 CV/YCM/CM)
Bearing inside dia.mm160
Spindle boremm105
TURRET
No. of toolsno.10 (opt. 12) (12 for CV/YCM/CM)
No. of live toolsno.6 (CV), 12 (YCM/CM)
Tool shank sizemm32
Curvic coupling dia. (mm)mm320 (250) [320/320]
Max. boring bar dia.mm50 (VDI-50) [BMT-75]
Exchange time (T-T)sec1
Milling speedrpm3000
Milling motorkW7.0
TAILSTOCK
Quill dia.mm150
Quill strokemm150
Quill taperMT#5 (live)
OTHER
CNC controller (FANUC)0i-T
Tank capacityL.950
Approx. machine sizem9.5 x 2.7 x 2.2 [2.9]
Net weightkg19500 [21500/20100]
